HT Icom IP503H
Communication throughout the Coverage of LTE (4G) and 3G Network
Using an existing LTE (4G) and 3G network, the IP503H is able to provide a network with wide area coverage capabilities. The IP503H does not require its own repeaters or IP network which reduces the cost of building and maintaining a wide area radio network.
Simultaneous TalkListen Function for Full-Duplex Communication
The Simultaneous TalkListen function provides full-duplex one-to-many communication which users can talk and receive at the same time like a telephone style conversation.
Multiple User Communication
Multiple users in the call groups can initiate calls instantaneously. Removing the need to wait for available channels to communicate.
Priority Interrupt Calling
The IP503 supports group calls with three or more people. In case of an emergency, you can break into an on-going call to transmit an important message.
Industry Leading Compact and Lightweight Body
Compact 59 × 95 × 32 mm; 2.3 × 3.7 × 1.3 in and 240 g; 8.5 oz (approximate) lightweight body* allows non-intrusive mobility and use.
IP67 Dust-Tight and Waterproof
The IP503H has been designed to preserve its waterproof integrity in water of a depth of 1 meter for 30 minutes. It can be used for outdoor work or places prone to get wet.
Optional Charger Cradle With Bluetooth® Function *1
When the optional BC-218, charger cradle and HM-215, speaker-microphone is used*2, calls can be made with the microphone, while charging the IP503H. Even when the IP503H is not dropped into the BC-218, the Bluetooth® function*1 enables you to wirelessly use the speaker-microphone.
Powerful and Clear Audio
The powerful 900mW speaker provides high-quality and clear audio, even in noisy environments.
Other Features
- Individual, Group, Talkgroup, Multiplex Talkgroup and All calls
- Emergency button, Lone Worker and Man Down functions
- Vibration alert function notifies of incoming call
- Text message reception and preprogrammed message transmission
- Up to 500 memory address book (including Group, Individual, Talkgroup and Telephone lists)
- Voice message recording
- Built-in Bluetooth® and GPS*
| Network | 4G bands | LTE B1, B3, B7, B8, B20 (EXP) LTE B1, B3, B5, B7, B8, B28 (AUS) |
|---|---|---|
| 3G bands | W-CDMA B1, B8 (EXP) W-CDMA B1, B5 (AUS) |
|
| Dimensions (W × H × D; Projections not included) |
59 × 95 × 32 mm; 2.3 × 3.7 × 1.3 in (with BP-272) |
|
| Weight (approx.) | 240 g; 8.5 oz (with BP-272 and antenna) |
|
| Voice Codec | G.726 (32 kbps) | |
| AF output power (8 Ω at 10% distortion) |
Internal SP | More than 900 mW |
| External SP | More than 200 mW | |
| Operating time*1 (TX : RX : standby = 5 : 5 : 90) |
More than 17 hours (with BP-272) | |
| Bluetooth*2 | Ver 2.1 +EDR | |
| GPS | Built-in | |
| Operating temperature | –10 °C to +60 °C; +14 °F to +140 °F | |
| IP rating | IP67 (dust-tight and immersion) IP55/54 (dust and water jet / water resistance) |
|
*1 Operating time may differ depending on operating environments. *2 Version without Bluetooth also available. Ask your Dealer for details.
All stated specifications are subject to change without notice or obligation.
Applicable U.S. Military Specifications
| Standard |
MIL-810 G | |
|---|---|---|
| Method | Procedure | |
| Low Pressure | 500.5 | I, II |
| High Temperature | 501.5 | I, II |
| Low Temperature | 502.5 | I, II |
| Temperature Shock | 503.5 | I-C |
| Solar Radiation | 505.5 | I |
| Rain Blowing/Drip | 506.5 | I, III |
| Dust Blowing | 510.5 | I |
| Immersion | 512.5 | I |
| Vibration | 514.6 | I |
| Shock | 516.6 | I, IV |
Also meets equivalent MIL-STD-810 -C, -D, -E and -F.
Supplied Accessories
- BP-272 Li-ion battery pack
- MB-135 belt clip
- Hand strap
- Antenna
