Connector RG8 Amphenol N Male
Detail Produk
Konektor RG8 N-Male Amphenol produksi dari Brand Amphenol. Konektor ini banyak digunakan utk Jumper Konektor Radio Base Station Series.
This male BNC Male Crimping Amphenol RF connector is designed for crimp attachment to the widely used RG58 and low-loss 195-series coaxial cables utilizing readily-available crimp tools with standard crimp sizes: .178″ for the crimp ferrule and .068″ for the pin. BNC connectors connect with a twist lock, making them popular for RF applications.
Features:
|
Applications:
|
Specifications:
| Electrical | |
| Impedance | 50 Ohms |
| Frequency Range | DC ~ 4 GHz |
| Voltage Rating | 500 Volts Peak |
| Dielectic Withstanding Voltage | 1500 Volts RMS |
| Insertion Loss | .20 dB Max. |
| Mechanical | |
| Mating | 2-Stud Bayonet Coupling |
| Mating Torque | |
| Cable Attachment | Hex Braid Crimp |
| Center Conductor Cable Attachment | Crimp or Solder |
| Cable Retention | 30 lbs. Pull |
| Material | |
| Body | Nickel Plated Brass |
| Contact | Gold Plated Brass |
| Insulator | TFE |
| Ferrule | Nickel Plated Brass |
| Environmental | |
| Temperature Range | -55C(-67F) to +85C(+185F) |
| Temperature Cycling | MIL-Std. 202 Method 102 (Test Condition D) |
| Weatherproof | All BNC Connectors are Weatherproof |
| Moisture Resistance | MIL-Std. 202 Method 106 |
| Corrosion | MIL-Std. 202 Method 101 (Test Condition B) |
| Vibration | MIL-Std. 202 Method 204 (Test Condition D) |
| Altitude | MIL-Std. 202 Method 105 (Test Condition C) |
